| Certificates |
| Certification | UL (UL 62368), CSA (CSA 22.2), CE mark, FCC Part 15 (CFR 47) Class A |
| Data transmission |
| Packet buffer memory | 8 MB |
| Switching capacity | 480 Gbit/s |
| Number of queues | 8 |
| Number of static routes | 990 |
| Jumbo frames | 9000 |
| Static route | Yes |
| Jumbo frames support | Yes |
| Design |
| Reset button | Yes |
| Product colour | Grey |
| Logistics data |
| Country of origin | China |
| Management features |
| Switch layer | L2/L3 |
| MIB support | Y |
| Configuring Location Settings (CLI) | Yes |
| Quality of Service (QoS) support | Yes |
| Web-based management | Yes |
| Multicast features |
| Multicast support | Yes |
| Network |
| Port mirroring | Yes |
| Rate limiting | Yes |
| Spanning tree protocol | Yes |
| Link aggregation | Yes |
| VLAN support | Yes |
| Head-of-line (HOL) blocking | Yes |
| Broadcast storm control | Yes |
| Policy-based routing | Yes |
| QinQ implementation | Selective QinQ |
| Virtual LAN features | Private VLAN, Voice VLAN |
| Networking standards | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3an, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| Cable types supported | Cat5e |
| Operational conditions |
| Storage temperature (T-T) | -25 - 70 °C |
| Operating temperature (T-T) | -5 - 50 °C |
| Storage relative humidity (H-H) | 10 - 90% |
| Operating relative humidity (H-H) | 10 - 90% |
| Heat dissipation | 300.76 BTU/h |
| Other features |
| Packaging content | Switch, power cable, USB Type C cable and mounting hardware |
| Packaging data |
| Package height | 105.9 mm |
| Package depth | 574.7 mm |
| Package width | 430 mm |
| Package weight | 5.6 kg |
| Performance |
| Plug and Play | Yes |
| Built-in processor | Yes |
| Memory type | DDR4-SDRAM |
| Flash memory | 512 MB |
| Mean time between failures (MTBF) | 427188 h |
| Processor frequency | 1.4 MHz |
| Internal memory | 1000 MB |
| Noise level | 39 dB |
| Ports & interfaces |
| Console port | RJ-45/USB Type-C |
| SFP+ module slots quantity | 12 |
| Power |
| Power consumption (typical) | 88.2 W |
| AC input voltage | 100 - 220 V |
| Power plug type | Type C |
| Power source | AC |
| AC input frequency | 50/60 Hz |
| Protocols |
| GARP VLAN Registration Protocol (GVRP) | Yes |
| IPv4 & IPv6 features | ICMPv6, IPv6 SNMP, IPv6 SSH, IPv6 TFTP, IPv6 Telnet |
| Security |
| DHCP features | DHCP auto-config, DHCP client, DHCP relay, DHCP server, DHCP snooping |
| Access Control List (ACL) rules | 1024 |
| Authentication | MAC-based authentication, Web-based authentication |
| Security algorithms | HTTPS, SNMP, SNMPv2, SNMPv3, SSH, SSH-2 |
| DoS attack prevention | Yes |
| Authentication type | RADIUS, TACACS+ |
| Queue scheduling algorithms | Weighted Round Robin (WRR) |
| IGMP proxy | Yes |
| Access Control List (ACL) | Yes |
| IGMP snooping | Yes |
| SSH/SSL support | Yes |
| Weight & dimensions |
| Depth | 273 mm |
| Width | 445 mm |
| Weight | 4.2 kg |
| Height | 44 mm |
